Automatic Cartoning Machine – Servo Motor Cartoner with Belt Feeding, PLC Control

Name: Automatic Cartoning Machine – Servo Motor Cartoner with Belt Feeding, PLC Control
Brand: SHANGHAI LIKEE MACHINERY MOULD CO.,LTD
SKU: LK-BC3115
Price: 64.00 USD
Availability: InStock

Brand Name:	LIKEE
Model Number:	LK-BC3115

Detail Information

Product Description

Detail Information

Place of Origin:

Shanghahi, China

Certification:

CE, SGS, ISO9001, and ISO14001

Product Name:

Automatic Cartoning Machine

Drive System:

Servo Motor Cartoner With Belt Feeding

Control System:

PLC Control

Application:

Suitable For Wet Wipes & Aluminum Foil Box Packaging

Working Speed:

10–50 Boxes/min

Box Size Range:

L100–320 × W100–190 × H30–100 Mm

Highlight:

Servo Motor Cartoner Automatic Cartoning Machine

PLC Control Cartoner

10–50 boxes/min Box Packaging Machine

Product Description

Automatic Cartoning Machine – Servo Motor Cartoner with Belt Feeding, PLC Control

Product Overview

The LK-BC3115 is an advanced automatic cartoning machine designed for aluminum foil paper packaging. This servo-driven cartoner features belt feeding, PLC control, and is specifically engineered for wet wipes and aluminum foil box packaging applications.

Equipped with a 1.5 kW servo motor, 0.25 kW feeding motor, and 3.5 kW heating device, this machine delivers reliable performance with adjustable box sizing and efficient operation requiring only one operator.

Technical Specifications

Machine Type	Aluminum foil paper packing machine (cartoning machine)
Suitable Products	Wet wipes, aluminum foil, plastic wrap, oil-absorbing paper, plastic bags
Working Speed	10-50 boxes/min
Packing Box Size (L×W×H)	100-320 × 100-190 × 30-100 mm
Feeding System	Belt conveyor
Control System	PLC
Servo Motor	1.5 kW
Feeding Motor	0.25 kW
Heating Device	3.5 kW
Adhesive Type	Hot melt adhesive or regular glue
Air Pressure	0.5-0.8 MPa
Electrical Requirements	380V, 50Hz, 3-phase
Overall Dimensions (L×W×H)	4000 × 1600 × 1700 mm
Weight	1500 kg

Key Features

Servo motor drive with 1.5 kW servo motor, 0.25 kW feeding motor, and 3.5 kW heating device
Belt feeding system using conveyor belt
Advanced PLC control for precise operation
Specifically designed for wet wipes, aluminum foil, plastic wrap, oil-absorbing paper, and plastic bags
Multi-directional box size adjustment (L 100-320 / W 100-190 / H 30-100 mm)
Working speed of 10-50 boxes per minute
Sealing with hot melt adhesive or regular glue options
380V, 50Hz, 3-phase power supply with 0.5-0.8 MPa air pressure requirement
Compact dimensions: 4000 × 1600 × 1700 mm; weight 1500 kg
One machine, one person operation for efficient labor utilization

Frequently Asked Questions

What products can this cartoning machine pack? Wet wipes, aluminum foil, plastic wrap, oil-absorbing paper and plastic bags.
What kind of motor does the machine use? The machine is equipped with a 1.5 kW servo motor, plus a 0.25 kW feeding motor and a 3.5 kW heating device.
How are products fed into the machine? By belt conveyor.
How is the machine controlled? By PLC.
What box sizes does the machine accept? Length 100-320 mm, width 100-190 mm, height 30-100 mm. The size is adjustable in multiple directions.
What is the working speed? 10-50 boxes per minute.
What adhesive does it use? Hot melt adhesive or regular glue.
What is the power supply? 380V, 50Hz, 3-phase; air pressure required 0.5-0.8 MPa.
What are the overall dimensions and weight? 4000 × 1600 × 1700 mm; 1500 kg.
How many operators are required? One. The machine is described as a one-machine, one-person operation.
