80 Ton Pressure Automatic Type Aluminium Foil Box Making Machine Silver Foil Making Machine

1 SET
MOQ
USD 78,000
Price
80 Ton Pressure Automatic Type Aluminium Foil Box Making Machine Silver Foil Making Machine
Features Gallery Product Description Request A Quote
Features
Specifications
Compressor: Max Pressure Not Less Than 0.8Mpa
Electric: 380V, 50HZ, 3Phase
Embossing: Can Be Customized As Per Sample
Working Speed: 30~75 Strokes/min
Material: High Precised Steel
Stacker: 1~5 Ways ( Customized As Per Sample)
Maximum Container: USA Full Size Pan
Minimum Container: Small Cake Tart Φ60*30mm
Total Power: 26KW
Color: White And Orange (Can Be Also Customized)
High Light:

Food Grade Aluminium Foil Box Making Machine

,

80 Ton Aluminium Foil Box Making Machine

,

80 Ton Silver Foil Making Machine

Basic Infomation
Place of Origin: CHINA
Brand Name: LIKEE
Certification: CE, ISO
Model Number: LK-T80
Payment & Shipping Terms
Packaging Details: Sea Shipping Standard Wooden Case
Delivery Time: 2 months
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1 sets 2 months
Product Description

80 Ton Pressure Automatic Type Aluminium Foil Box Making Machine Silver Foil Making Machine



Components:
Decoiler 1200mm
Press Machine 80Ton
Auto Stacker With 4 Ways

Scrap Aspirator
Mould Lifter
Scrap Baler ( It's optional part. It can connect two production line)



Basic Specification

ITEM LK-63T LK-80T
Strokes 30-75times/min 30-75times/min
Voltage

3-380V 50HZ

4wires

3-380V 50HZ

4wires

Total Weight

9.2KGS

(approximate)

10.5KGS

(approximate)

Area 6.5mx6m 7.5mx7.0m
Core Coil Head Dia 3min/6inch 3min/6inch
Max. Foil Roll Outer Dia 700mm 800mm
Embossing Device Can be added  Can be added
Oil System Machine Grease Closed Oil System
Stacker Ways  1~3 Ways  1~4 Ways
Structure  "C" Frame  "H" Frame
Total Power 18.5KW 26KW
Max. Foil Width 780mm 1050mm








80 Ton Pressure Automatic Type Aluminium Foil Box Making Machine Silver Foil Making Machine 0



80 Ton Pressure Automatic Type Aluminium Foil Box Making Machine Silver Foil Making Machine 1

80 Ton Pressure Automatic Type Aluminium Foil Box Making Machine Silver Foil Making Machine 2

80 Ton Pressure Automatic Type Aluminium Foil Box Making Machine Silver Foil Making Machine 380 Ton Pressure Automatic Type Aluminium Foil Box Making Machine Silver Foil Making Machine 480 Ton Pressure Automatic Type Aluminium Foil Box Making Machine Silver Foil Making Machine 580 Ton Pressure Automatic Type Aluminium Foil Box Making Machine Silver Foil Making Machine 680 Ton Pressure Automatic Type Aluminium Foil Box Making Machine Silver Foil Making Machine 7

80 Ton Pressure Automatic Type Aluminium Foil Box Making Machine Silver Foil Making Machine 8



Company Brife Introduction



80 Ton Pressure Automatic Type Aluminium Foil Box Making Machine Silver Foil Making Machine 9





80 Ton Pressure Automatic Type Aluminium Foil Box Making Machine Silver Foil Making Machine 10



80 Ton Pressure Automatic Type Aluminium Foil Box Making Machine Silver Foil Making Machine 11





FAQ

Q1: Do you accept customized orders?
A: Yes, we do.
Q2: what about leadtime?
A: The fastest delivery can be 5~6 weeks once the order is confirmed.
Q3: What are the terms of payment and currencies do you accept?
A: T/T,L/C at sight ,Cash,Paypal,Western Union.
Q4: How to purchase raw material or lubricating oil?
A: LIKEE can support every purchase work for all our customers, to help you set up a matured factory at the fast step.
Q5: Warranty for machines and moulds?
A: We gurantee a period of 12 months from the date of machine & mould installation and setting to work.
Q6:How to install machine and train our staff on our factory?
A: Yes, we do.

We’ll send our engineers to your factory to install, test machines and give your workers training guidance.
