Pop Up Wax Paper Folding Machine, V-Fold Cross Folding Continuous Extraction

The LKWP-980 is a pop up wax paper folding machine that folds wax paper or one-sided silicone paper into interleaved sheets. Sheets are folded in a V-fold cross pattern and stacked in continuous extraction order: pulling one sheet lifts the next one, so staff at a counter or on a tray line take a single sheet without separating a stack.

Standard finished sheet is 270 mm unfolded and 135 mm folded, and finished width is slit within a 950 mm range from a roll up to 930 mm wide. Paper runs from a 76 mm core at 30 to 60 gsm. One row folds 250 to 400 sheets per minute, and total output multiplies by the number of slitting rows. Serrated or straight cut-off is set by tooling change, and the machine is controlled from a 7-inch touch screen.

The machine suits converters and food service suppliers who pack wax paper sheets for sandwich wrap, deli sheets and bakery liners. Sheet length and slitting width are both customizable, so one machine platform covers several sheet sizes. LIKEE has built aluminum foil and paper converting machinery since 2010 and provides overseas installation service.

• V-fold cross folding with continuous (pop-up) extraction.
• Multi-row slitting: finished sheet width is cut within a 950 mm range on one web.
• Standard finished sheet of 270 mm unfolded and 135 mm folded; other lengths made to order.
• Single-row folding speed of 250 to 400 sheets per minute; total output is that speed multiplied by the number of slitting rows.
• Serrated or straight cut-off from the same machine.
• Runs 30 to 60 gsm wax paper and one-sided silicone paper from a 76 mm core.
• 7-inch touch screen control.

• Pop-up interleaving saves time at the counter: staff pull one sheet at a time and do not unfold or separate a stack by hand.
• A 270 mm standard sheet length with other lengths made to order means a new sheet size is handled by tooling and settings instead of a second machine.
• The 950 mm slitting width takes a roll up to 930 mm wide, so one machine covers the sheet widths you sell.
• Output scales with slitting rows, so one machine covers volume that would otherwise need several single-lane lines.
• A dedicated tension motor holds web tension through the fold and cut-off, which keeps the fold and the cut edge steady at running speed.
• One machine covers both wax paper and one-sided silicone paper.
• LIKEE has supplied aluminum foil and paper converting machinery since 2010 and provides overseas installation service.
